Technical specifications:
Color LCD screen 1.77”
GPS
Output power (w): 3w-5w
Battery capacity (mAh): 1800
Water resistance: IP55
Storage channels: 999
Frequency Range:
Reception of 6 bands,
Transmission of three bands
Maximum range: 3km-5km
Channel spacing 25.0KHz/12.5KHz
Input voltage 7.4 VDC
Current Drain:
Standby 45 mA
Reception 380 m
Transmission ≤1.6A (High power), ≤1.2A (Low power)
Operating temperature -10°c to 60°c
Antenna impedance 50 ohm
Dimensions 135mm*61mm*39mm (without antenna)
Weight 260g (with battery)
Transmitter
Frequency range (TX) 136-174MHz & 200-260MHz & 400-520MHz
RF output power 5 Watt
Modulation 16K ΦF3E/11K ΦF3E
Spurious Emission -16dBm< 1GHz, -16dBm> 1GHz
Frequency Stability ±2.5 ppm
Audio distortion ≤5%
FM Hum & Noise 40dB
Receiver
Frequency Range
VHF2: 136-174 MHz & UHF 400-520 MHz (Scanning receiver)
FM: 65-108 MHz (RX) AM: 108-130 MHz (RX)
VHF1: 350-355 MHz (RX)
VHF3: 200-260 MHz
Sensitivity: 12dB SINAD -120dBM
Adjacent channel selectivity -60dBm
Modulation and rejection -70dBm
Rated audio output power 0.75Wats 16ohm
Rated audio distortion ≤5%
